1 @ HAAS VF-2
• X,Y,Z STROKE 30″, 16″, 20″
• 20 HP GEAR DRIVEN SPINDLE
• 7500 RPM SPINDLE SPEED
• HIGH SPEED RIGID TAPPING
• 20 POSITION TOOL CHANGER
• POSITION / REPEATABILITY 0.0002″ / 0.0001″
1 @ BROTHER SPEEDIO SX700X1
4 AXIS VERTICAL MACHINING CENTRE
• X,Y,Z STROKE 27.6”, 15.70”, 11.80”
• 9.8 HP
• 16,000 RPM SPINDLE SPEED
• HIGH SPEED RIGID TAPPING UP TO 6000 RPM
• 21 POSITION TOOL CHANGER, (TURRET STYLE)
• TOOL CHANGE (TOOL TO TOOL) 0.8 SECONDS
• TOOL CHANGE (CHIP TO CHIP) 1.4 SECONDS
• POSITION (INCH) 0.00024″ / 0.00079″
• REPEATABILITY (INCH) 0.00016”
1 @ HAAS VF-4BHS
• X,Y,Z STROKE 50″, 20″, 25″
• 30 HP GEAR DRIVEN SPINDLE
• 10,000 RPM SPINDLE SPEED
• HIGH SPEED RIGID TAPPING
• 20 POSITION TOOL CHANGER
• POSITION / REPEATABILITY 0.0002″ / 0.0001″
1@HAAS VF-2 SS
• X,Y,Z STROKE 30″, 16″, 20″
• 30 HP GEAR DRIVEN SPINDLE
• 12,000 RPM Spindle Speed
• HIGH SPEED RIGID TAPPING
• 24-Tool High Speed Tool Changer
• POSITION / REPEATABILITY 0.0002″ / 0.0001″Description
2 @ HAAS VF-2BHS
• X,Y,Z STROKE 30″, 16″, 20″
• 30 HP GEARED HEAD DRIVE
• 10,000 RPM SPINDLE SPEED
• HIGH SPEED RIGID TAPPING
• 20 POSITION TOOL CHANGER
• POSITION / REPEATABILITY 0.0002″ / 0.0001″Description
1 @ HAAS VF-3BHS
• X, Y, Z STROKE 40”, 20”, 25”
• 30 HP GEARED HEAD DRIVE
• 10,000 RPM SPINDLE SPEED
• HIGH SPEED RIGID TAPPING
• 20 POSITION TOOL CHANGER
• POSITION / REPEATABILITY 0.0002” / 0.0001”Description
